Hot selling screw terminal LiFePO4 type 3.2V 12Ah rechargeable lithium ion battery
Model No.:F12-1865150
Nominal voltage:3.2V
Nominal capacity:12Ah
Internal resistance:≤3.5mΩ
Max. continuous charge current:1C
Max. continuous discharge current:3C
Max. impulse discharge current:5C
Cycle life:≥2000 times
Charge temperature:0°C~45°C
Discharge temperature:-20°C~60°C
Storage temperature:-20°C~45°C
Weight:325g
Dimension:18mm*65mm*150mm
Application:Make battery packs for power supply and energy storage systems
★LiFePO4 prismatic cells, the pinnacle of lithium battery technology. These prismatic battery cells are engineered with precision and innovation, offering unparalleled performance and reliability for a wide range of applications.
★LiFePO4 battery or lithium iron phosphate battery, is renowned for its exceptional stability, safety, and longevity compared to traditional lithium-ion batteries.
1. The 3.2V 12Ah prismatic LiFePO4 battery cell with aluminum hard case.
2. Dimension: 18*65*150mm, including bolts, not including PVC film, tolerance±0.5mm.
3. Nominal capacity: 12Ah, based on 25±5℃， 0.2C， CC (constant current) discharged to 2V.
4. Standard charge current: 2.4A = 0.2C， CC (constant current) charged to 3.65V, then CV (constant voltage) 3.65V till current decline to 240mA.
5. Max charge current: 12A = 1C， CC (constant current) charged to 3.65V, then CV (constant voltage) 3.65V till current decline to 240mA
6. Standard discharge current: 2.4A = 0.2C, CC (constant current) discharged to 2V.
7. Max continuous discharge current: 36A = 3C, CC (constant current) discharged to 2V.
8. Max peak discharge current: 60A = 5C, lasting time less than 1 min.
9. Screw terminal design: Very easy for assembling
10. No memory effect, high discharge rate, high energy density.
11. Cycle life: more than 2000 times. Our prismatic cell standard charge is at 0.2C CC/CV to 3.65V, cut off when current≤0.02C at 25±5℃. Standard discharge at 0.5C CC to 2Vat 25±5℃. Repeat the cycle of standard charge and discharge, when the battery capacity is less than 80% of the nominal capacity, stop the test.
12. Storage: when the prismatic-cell battery need to be long-term stored, charge the battery to about 10%-20% capacity, store it in dry and ventilated place, charge and discharge battery one time every 6 months.
LiFePO4 BATTERY COMPANY
Hangzhou LIAO Technology Co.,Ltd
Was established in 2009, with many years of experience We are a professional and leading manufacturer specializedin LiFePO4 batteries.
Our professional custom battery pack solutions help you save a lot of time and money, as well as get established on the market quickly. If you are looking for a custom battery pack manufacturer in China, please contact us for more details.
Production area
Production capacity
Global customers
15
YEARS OF
LIFEPO4 BATTERY
1. Are you factory?
A: Yes, we are factory at Zhejiang China. Welcome to visit our company at any time.
2. Do you have current sample in stock?
A: Usually we don't have, because different customers have different requests, even the voltage and capacity are the same, other parameters maybe different. But we could finish your sample quickly once order confirmed.
3.0EM & ODM are available?
A:Sure, OEM&ODM are welcome and Logo can be customized too.
4.What's the delivery time for mass production?
A: Usually 15-25days, it depends on the quantity, material, battery cell model and so on, we suggest to check delivery time case by case.
5.What is your MOQ?
A: 1PCS sample order can be acceptable for testing
6.What is the normal lifetime about battery?
A: More than 800 times for lithium ion battery; more than 2,000 times for LiFePO4 lithium battery.
7.Why choose LIAO Battery?
A: 1) A professional sales team which provide consultant service and the most competitive battery solutions.
2) Wide-range battery products to satisfy different customer's requirement.
3) Quick response, every inquiry will be replied within 24 hours.
4) Good after-sale service, long product warranty and continual technique support.
5) With 15 years-experience for manufacturing LiFePO4 battery.
Hangzhou LIAO Technology Co.,Ltd is professional and leading manufacturer specialized in LiFePO4 batteries and Exporting of Green Clean Energy and relevant products.
The lithium batteries produced by the company has good safety performance, long cycle life and high efficiency.
Products range from LiFePo4 batteries, , BMS board, Inverters, as well as other relevant electrical products which can be widely used in ESS/UPS/Telecom Base Station/Residential and commercial energy storage system/ Solar Street Light/ RV/ Campers/ Caravans/ Marine /Forklifts/ E-Scooter/ Rickshaws/ Golf Cart/ AGV/ UTV/ ATV/ Medical machines/ Electric wheelchairs/Lawn mowers, etc.
The lithium iron phosphate battery products have been exported to USA, Canada, UK, France, Germany, Norway, Italy, Sweden, Switzerland, Australia, New Zealand, Jamaica, Barbados, Panama, Costa Rica, Russia, South Africa, Kenya, Indonesia, the Philippines and other countries and regions.
With over 15 years’ experience and rapid growth, Hangzhou LIAO Technology Co.,Ltd is committed to providing our esteemed customers with reliable quality lithium iron phosphate batteries systems and integration solutions and will continue to innovate and improve its renewable energy products to help the world create a more eco-friendly, cleaner and brighter future.
